Thursday, December 18, 2014

Using 'Home-Made' Fortran Binary as Python module

Python is easy to use, but it's slow, especially for loop computation. So I compute it using fortran like this

        subroutine subs(a, b, n)
        double precision a(n)
        double precision b(n)
        integer n
cf2py   intent(in) :: a
cf2py   intent(out) :: b
cf2py   intent(hide) :: n
!        b(1) = a(1)
        do 100 i=2, n
                b(i) = a(i)-1
100     continue
        end


save it as aravir.py and do the following command
$ f2py -c aravir.f -m aravir

To use the module on the python I use the code below
import numpy as np
import aravir as ar

a = np.linspace(0,1,100)

b = ar.subs(a)

print a
print b

:)


3D Waterwave Simulation using Python

I used Numpy  Matplotlib with Animation and 3d Plot module on my OS X Yosemite.

The code is still messy and clearly not efficient (there's slow loop here and there) but it works, :)
Here The Result
The Code
import numpy as np

n = 8;
g = 9.8;
dt = 0.02;
dx = 1.0;
dy = 1.0;

h = np.ones((n+2,n+2))
u = np.zeros((n+2,n+2))
v = np.zeros((n+2,n+2))

hx = np.zeros((n+1,n+1))
ux = np.zeros((n+1,n+1))
vx = np.zeros((n+1,n+1))

hy = np.zeros((n+1,n+1))
uy = np.zeros((n+1,n+1))
vy = np.zeros((n+1,n+1))

nsteps = 0
h[1,1] = .5;

def reflective():
    h[:,0] = h[:,1]
    h[:,n+1] = h[:,n]
    h[0,:] = h[1,:]
    h[n+1,:] = h[n,:]
    u[:,0] = u[:,1]
    u[:,n+1] = u[:,n]
    u[0,:] = -u[1,:]
    u[n+1,:] = -u[n,:]
    v[:,0] = -v[:,1]
    v[:,n+1] = -v[:,n]
    v[0,:] = v[1,:]
    v[n+1,:] = v[n,:]

def proses():
    #hx = (h[1:,:]+h[:-1,:])/2-dt/(2*dx)*(u[1:,:]-u[:-1,:])
    for i in range (n+1):
        for j in range(n):
            hx[i,j] = (h[i+1,j+1]+h[i,j+1])/2 - dt/(2*dx)*(u[i+1,j+1]-u[i,j+1])
            ux[i,j] = (u[i+1,j+1]+u[i,j+1])/2- dt/(2*dx)*((pow(u[i+1,j+1],2)/h[i+1,j+1]+ g/2*pow(h[i+1,j+1],2))- (pow(u[i,j+1],2)/h[i,j+1]+ g/2*pow(h[i,j+1],2)))
            vx[i,j] = (v[i+1,j+1]+v[i,j+1])/2 - dt/(2*dx)*((u[i+1,j+1]*v[i+1,j+1]/h[i+1,j+1]) - (u[i,j+1]*v[i,j+1]/h[i,j+1]))

    for i in range (n):
        for j in range(n+1):
            hy[i,j] = (h[i+1,j+1]+h[i+1,j])/2 - dt/(2*dy)*(v[i+1,j+1]-v[i+1,j])
            uy[i,j] = (u[i+1,j+1]+u[i+1,j])/2 - dt/(2*dy)*((v[i+1,j+1]*u[i+1,j+1]/h[i+1,j+1]) - (v[i+1,j]*u[i+1,j]/h[i+1,j]))
            vy[i,j] = (v[i+1,j+1]+v[i+1,j])/2 - dt/(2*dy)*((pow(v[i+1,j+1],2)/h[i+1,j+1] + g/2*pow(h[i+1,j+1],2)) - (pow(v[i+1,j],2)/h[i+1,j] + g/2*pow(h[i+1,j],2)))

    for i in range (1,n+1):
        for j in range(1,n+1):
            h[i,j] = h[i,j] - (dt/dx)*(ux[i,j-1]-ux[i-1,j-1]) - (dt/dy)*(vy[i-1,j]-vy[i-1,j-1])
            u[i,j] = u[i,j] - (dt/dx)*((pow(ux[i,j-1],2)/hx[i,j-1] + g/2*pow(hx[i,j-1],2)) - (pow(ux[i-1,j-1],2)/hx[i-1,j-1] + g/2*pow(hx[i-1,j-1],2))) - (dt/dy)*((vy[i-1,j]*uy[i-1,j]/hy[i-1,j]) - (vy[i-1,j-1]*uy[i-1,j-1]/hy[i-1,j-1]))
            v[i,j] = v[i,j] - (dt/dx)*((ux[i,j-1]*vx[i,j-1]/hx[i,j-1]) - (ux[i-1,j-1]*vx[i-1,j-1]/hx[i-1,j-1])) - (dt/dy)*((pow(vy[i-1,j],2)/hy[i-1,j] + g/2*pow(hy[i-1,j],2)) - (pow(vy[i-1,j-1],2)/hy[i-1,j-1] + g/2*pow(hy[i-1,j-1],2)))

#dh = dt/dt*(ux[1:,:]-ux[:-1,:])+ dt/dy*(vy[:,1:]-vy[:,:-1])
    reflective()
    return h,u,v
'''
for i in range (17):
    #print h
    proses(1)
'''

import matplotlib.pyplot as plt
from matplotlib import cm
from matplotlib.ticker import LinearLocator, FormatStrFormatter
from mpl_toolkits.mplot3d import Axes3D
a = n
x = np.arange(n+2)
y = np.arange(n+2)
x,y = np.meshgrid(x,y)

fig = plt.figure()

ax = fig.add_subplot(111, projection='3d')

def plotset():
    ax.set_xlim3d(0, a)
    ax.set_ylim3d(0, a)
    ax.set_zlim3d(0.5,1.5)
    ax.set_autoscalez_on(False)
    ax.zaxis.set_major_locator(LinearLocator(10))
    ax.zaxis.set_major_formatter(FormatStrFormatter('%.02f'))
    cset = ax.contour(x, y, h, zdir='x', offset=0 , cmap=cm.coolwarm)
    cset = ax.contour(x, y, h, zdir='y', offset=n , cmap=cm.coolwarm)
    cset = ax.contour(x, y, h, zdir='z', offset=.5, cmap=cm.coolwarm)

plotset()

surf = ax.plot_surface(x, y, h,rstride=1, cstride=1,cmap=cm.coolwarm,linewidth=0,antialiased=False, alpha=0.7)

fig.colorbar(surf, shrink=0.5, aspect=5)


from matplotlib import animation


def data(k,h,surf):
    proses()
    ax.clear()
    plotset()
    surf = ax.plot_surface(x, y, h,rstride=1, cstride=1,cmap=cm.coolwarm,linewidth=0,antialiased=False, alpha=0.7)
    return surf,

ani = animation.FuncAnimation(fig, data, fargs=(h,surf), interval=10, blit=False)
#ani.save('air.mp4', bitrate=512)
plt.show()

and the snapshot






Wednesday, December 17, 2014

3D Surface Plot Animation using Matplotlib in Python

And here's the animation
import numpy as np
import matplotlib.pyplot as plt
import matplotlib.animation as animation
from mpl_toolkits.mplot3d import Axes3D

def data(i, z, line):
    z = np.sin(x+y+i)
    ax.clear()
    line = ax.plot_surface(x, y, z,color= 'b')
    return line,

n = 2.*np.pi
fig = plt.figure()
ax = fig.add_subplot(111, projection='3d')

x = np.linspace(0,n,100)
y = np.linspace(0,n,100)
x,y = np.meshgrid(x,y)
z = np.sin(x+y)
line = ax.plot_surface(x, y, z,color= 'b')

ani = animation.FuncAnimation(fig, data, fargs=(z, line), interval=30, blit=False)

plt.show()

The result

The snapshot



3D Surface Plot using Matplotlib in Python

It's slightly modified from before

import numpy as np
import matplotlib.pyplot as plt
import matplotlib.animation as animation
from mpl_toolkits.mplot3d import Axes3D

n = 2.*np.pi
fig = plt.figure()
ax = fig.add_subplot(111, projection='3d')

x = np.linspace(0,n,100)
y = np.linspace(0,n,100)
x,y = np.meshgrid(x,y)
z = np.sin(x+y)
line = ax.plot_surface(x, y, z,color= 'b')

plt.show()


the result


the snapshot



Matplotlib Animation in Python

Here is the update from before

import numpy as np
import matplotlib.pyplot as plt
import matplotlib.animation as animation

def simData():
    t_max = n
    dt = 1./8
    k = 0.0
    t = np.linspace(0,t_max,100)
    while k < t_max:
        x = np.sin(np.pi*t+np.pi*k)
        k = k + dt
        yield x, t

def simPoints(simData):
    x, t = simData[0], simData[1]
    line.set_data(t, x)
    return line
n = 2.
fig = plt.figure()
ax = fig.add_subplot(111)
line, = ax.plot([], [], 'b')
ax.set_ylim(-1, 1)
ax.set_xlim(0, n)

ani = animation.FuncAnimation(fig, simPoints, simData, blit=False,\
                              interval=100, repeat=True)
plt.show()

and the result

Tuesday, December 16, 2014

Playing with Matplotlib Animation in Python

Coding like this

import numpy as np
from matplotlib import pyplot as plt
from matplotlib import animation

fig = plt.figure()
n = 10
x = np.linspace(0,2*np.pi,100)



def init():
    pass
def animate(k):
    h = np.sin(x+np.pik)
    plt.plot(x,h)


ax = plt.axes(xlim=(0, 2*np.pi), ylim=(-1.1, 1.1))

anim = animation.FuncAnimation(fig, animate,init_func=init,frames=360,interval=20,blit=False)

plt.show()

The result

Thursday, December 4, 2014

Playing (again) with 'Home Made' Vector in Delphi

Here it is. I create a vector as new type, which is in itself is three dimension array.

Then I declared u as vector with three dimension;
u (h,i,j)

where h = 0, 1, 2  as physical component (eg: height, velocity, momentum)
i , j = 0, 1, 2, ..., n as row n column


So if we read u[0,1,1], it means height value at coordinate (1,1); u[1,1,1] is the velocity value; [2,1,1] is the momentum value at the same coordinate.


Trying some of properties of it. I found out that we can initialize all component of vector-u with this one line code

u:=fu(h[i,j],i,j);

so the component u(h,i,j) will filled. Notice that the function has vector (or in this case array) return value.

Tuesday, November 25, 2014

Returning Function as Array in Delphi

Do you wonder how to do vector operation in Delphi? No, of course, :).

We could go like this.

function tform1.adv(a,b:real):real;
begin
  adv:=a+b;
end;

The problem is the return is real, which is single value only. We want a and b as vector. Wait...

How we define vector in Delphi? I don't know. I used to treat a vector in Delphi as array. So I coded it like this

var a,b:array[0..1]of real;

So far I had no problem. Lately, I am going crazy with overuse functions in Delphi, and trying operating vectors using function too.

But if I write the code like this
function tform1.adv(a,b:array[0..1]of real):real;
begin
  adv:=a[0]+b[0];
  {a[1]+b[1]?}
end;

It will only return one value. So I improvised by modify it

Monday, November 17, 2014

Delphi: Click a Cell on Stringgrid to Toggle its Value

Here we are. The code below is a part of (unfinished) array of JK flip-flop that draw the output on stringgrid. The problem is, we want to change input (J and K) at  the runtime which is easy if the code is not flexible (just add several button), but as we can see, the code is flexible so there is big no no for the manually added button. So we want to click the corresponding cell and the value changed (in this case toggled, 1 to 0 or otherwise).

Here the code

Sunday, November 16, 2014

Digital Counter with Reset and Preset/Clear

This code's updated version from flexible one (whic is by itself is updated version from this) :) .

It has added feature so we could reset the counter if it reach a certain denary (decimal, it is :) ) and preset it to certain denary.

To be able to do that we have to convert the denary to binary and distribute it among Q[0] to Q[n-1].
